A Technical Assessment of Combine Header Selection for Minimizing Harvest Loss

If you want to minimize harvest loss, stop looking only at the back of your machine. Your combine header, the piece of equipment that cuts and gathers the crop, is where the vast majority of your money is lost or saved.

We often think of the header as just a feeder, but the data is blunt: the front of the combine is responsible for up to 60% of all corn loss and a staggering 80% to 90% of all soybean loss.¹ When your in-cab monitor reports a low loss rate, it’s often lying to you; those monitors only measure loss out the rear of the machine, missing the massive gathering losses happening right up front.⁵

Optimal header selection is not just a capital expenditure—it’s a calculated, yield-recovering investment. Treat the header as the primary yield capture system, and you will see the return in your bin.

Part 1: First, Know Your Loss Numbers (The Audit)

Before you can fix the problem, you have to measure it. Losses of 2% to 4% are common, but anything over 3% should trigger an immediate adjustment.⁶ Your goal should be 1% loss, which balances productivity and yield retention.⁸

The Quick Loss Test

Because your loss monitor misses most of the gathering loss, you must manually audit. Back the combine up 20 feet and use a 10-square-foot frame (or estimate the area) in front of where the back of the combine has passed to isolate only the grain lost at the head.¹⁰

Crop	Loss Measurement Rule of Thumb	Loss Source
Corn	20 kernels in a 10 sq. ft. area	Equals 1 bushel per acre lost ⁵
Corn	1 whole ear in 100 plants	Equals approximately 1% yield loss ¹³
Soybeans	4–5 beans per square foot	Equals 1 bushel per acre lost ¹⁷

Part 2: Corn Heads – The Precision Game

Corn loss at the head is almost entirely mechanical: whole ears are either dropped at initial contact (lodging) or shelled and bounced out by the snapping rolls.¹³ The precision of your deck plates is the single greatest factor controlling this loss.

1. What to Look for in Your Current Corn Head

If you run a conventional head, check two critical areas:

Deck Plate Gaps: Deck plates must be tight enough to capture the ears but wide enough to let the stalk through.¹⁴ The recommended maximum gap is about 3/4 inch.²⁰ Here is the brutal truth: a deck plate gap just
1/8 inch wider than the stalk can cost you 1 to 4 bushels per acre.²¹
Drive System Health: As chains, sprockets, and gearboxes wear, your drive system loses efficiency, increasing the risk of untimely breakdowns.²² If you are constantly replacing worn parts, you need to weigh the repair costs versus replacement.²² Some advanced heads now use spiral-cut, gear-driven systems designed for less wear than traditional straight-cut gears.²²

2. Why Buy a New Corn Head (The Case for Automation)

The biggest flaw in conventional hydraulic deck plates is stalk variability. Research shows that stalk width can differ by over 1/4 inch across the head 40% of the time.²¹ This means a single, hydraulic setting is Incorrect over 80% of the time.

The ROI is found in Automatic Self-Adjusting Deck Plates. These systems continuously measure the stalk entering each row unit and micro-adjust the gap. ²¹ The numbers are compelling: one study recorded that automatic deck plates made over 6,130 adjustments of 1/8 inch or more per acre.²⁴ This continuous, localized precision ensures the gap is always right against the stalk, maximizing kernel and ear capture.²⁶ If you farm high-yielding acres (over 200 bu/ac), stalk variability is even greater ²¹, making this technology less of a luxury and more of a necessity.

Part 3: Soybeans – The Ultra-Low Cut Challenge

For soybeans, header loss is the overwhelming majority of total loss (up to 90% in some cases).² The challenge is cutting the crop as close to the ground as possible to minimize stubble loss while preventing brittle pods from opening (shatter loss).²

1. Auger vs. Draper: The Flow Advantage

Header Type	Key Characteristic	Primary Risk/Challenge
Flex Auger (Conventional)	Uses a large, horizontal auger to pull the crop to the center.²⁸ Lower initial cost.⁶	Prone to “slugging” (bunching material) in damp or tough conditions, leading to greater shatter loss.²
Flexible Draper	Uses continuous rubber belts (drapers) for gentle, consistent flow.³⁰ Designed for ultra-low cutting.⁶	Higher initial cost.⁶

The Draper Justification: The most powerful case for the flexible draper is its flow consistency.²⁸ When conditions are tough or damp, the draper keeps feeding smoothly.² Farmers with drapers report being able to run 2 to 3 hours later every night, when pods have regained moisture and are less brittle, avoiding massive shatter loss.³¹ This enhanced flow minimizes both reel and auger shatter, often yielding an estimated 1 to 2 bu/ac advantage over conventional auger heads.³¹

2. Must-Have Technology for Soybeans

Active Float Systems: Soybeans require the cutterbar to “hug” the ground. Systems like HydraFlex and Active Float are engineered to support up to 97% of the header weight, allowing the cutterbar to track ground contours instantly without pushing soil.³³ This prevents the header from riding too high and leaving pods on the stubble.²⁸
Air Reels: Shatter loss happens the moment the knife touches the plant. Air reel systems aim a continuous curtain of high-velocity air at the cutterbar.¹ A PAMI study confirmed that using an air reel system could
Save 1.25 bushels per acre compared to harvesting without one, a direct yield recovery that quickly pays for the investment.¹¹

3. Tips for Tough Conditions (Green Stems)

When you encounter Green Stem Syndrome (GSS), waiting for the stems to dry is not an option—your brittle pods will shatter. You must cut:

Slow Down: Reduce ground speed to 2.5 to 3.0 mph or less.¹⁴ Harvest speed above
4 mph can increase header losses by nearly 40%.
Cut at an Angle: Try harvesting at a 20- to 25-degree angle to the rows to improve the cutterbar’s ability to sever the tough stems.
Synchronize the Reel: The reel speed should be set 10-25% faster than your ground speed to gently sweep the crop onto the belts without causing catastrophic shatter.²⁷ If the reel is too fast, you are wasting money ³⁴
Adjust Internal Threshing: To handle the tough stems, increase cylinder/rotor speed and add concave inserts to the front portion of the concave to keep the green pods in the threshing chamber longer for better separation.

Part 4: The Financial Case for the Upgrade

When evaluating a new header, the ROI is not just the lost bushels you save today; it’s the future value of the asset.

Bushel Savings Pay the Bill: If a new technology, like a draper head, consistently captures just 2 bu/ac that your old head missed, that revenue quickly justifies the initial price difference over a large acreage.²⁹
Depreciation is Your Friend: Flexible Draper headers have demonstrated significantly better asset retention than their rigid auger counterparts. Analyzing 2015 models, 40-foot and wider Flexible Draper heads only depreciated by 37% over three years, compared to 41% for rigid auger heads.²⁵ That 4-5 percentage point advantage means a lower net cost to own the superior technology.
Time is Money (and Yield): The superior feeding of a draper head, which allows you to run productively for more hours each day, accelerates harvest.²¹ This timeliness is the ultimate risk management—it protects your entire yield from the next unexpected rain or windstorm.

Stop relying solely on the rear-of-machine loss monitor; the vast majority of yield loss is happening immediately at the cut, often hidden from view.¹ Your first step is committing to a manual audit—the 20 kernels and 5 beans tests—to reveal your farm’s true revenue bleed.¹⁷ Every investment in advanced equipment, from flexible drapers to self-adjusting corn plates, is simply capital spent on proven yield recovery. Treat your header not as an accessory, but as the most critical financial tool for harvest profitability.

Works cited

Verifying Combine Adjustments During Crop Harvest, accessed September 29, 2025, https://crops.extension.iastate.edu/cropnews/2019/09/verifying-combine-adjustments-during-crop-harvest
Reducing Soybean Harvest Losses in Manitoba, accessed September 29, 2025, https://manitobapulse.ca/wp-content/uploads/2017/09/The-Bean-Report-May-2017_WR.pdf
Design and Experiment of a Harvesting Header for Wide–Narrow-Row Corn – MDPI, accessed September 29, 2025, https://www.mdpi.com/2076-3417/14/3/1309
Active Header Float (Optional) – Rigid Platforms, accessed September 29, 2025, http://manuals.deere.com/omview/OMH229937_19/OUO6075_000060F_19_22AUG07_1.htm
Profitable Corn Harvesting – Iowa State University, accessed September 29, 2025, https://crops.extension.iastate.edu/files/inline-files/PM574.pdf
Steps to Prevent Harvest Loss: Combine Settings and Preventative Maintenance, accessed September 29, 2025, https://www.beckshybrids.com/resources/agronomy-talk/steps-to-prevent-harvest-loss-combine-settings-and-preventative-maintenance
X Series Combine and Front-End Equipment Optimization – “Ready To Harvest” for Soybeans and Grain Quality – John Deere, accessed September 29, 2025, https://www.deere.com/assets/pdfs/common/qrg/x9-rth-soybeans.pdf
How to reduce combine loss | Canola Council of Canada, accessed September 29, 2025, https://www.canolacouncil.org/canola-watch/fundamentals/how-to-reduce-combine-loss/
Harvest Research – Drago Corn Heads, accessed September 29, 2025, https://www.dragotec.com/harvest-research/
Measuring Field Losses from Grain Combines | CAES Field Report – UGA, accessed September 29, 2025, https://fieldreport.caes.uga.edu/publications/B973/measuring-field-losses-from-grain-combines/
How to Estimate Harvest Losses in Soybean and Corn Fields | CropWatch | Nebraska, accessed September 29, 2025, https://cropwatch.unl.edu/2023/how-estimate-harvest-losses-soybeans-and-corn-fields/
Measuring Field Losses from Grain Combines, accessed September 29, 2025, https://secure.caes.uga.edu/extension/publications/files/pdf/B%20973_3.PDF
Measuring and Reducing Corn Field Losses | Pioneer® Seeds, accessed September 29, 2025, https://www.pioneer.com/us/agronomy/corn-field-losses.html
ROW BY ROW – Drago Corn Heads, accessed September 29, 2025, https://www.dragotec.com/wp-content/uploads/2023/03/Harvest_Report_2020.pdf
Identifying Factors Influencing Your Corn Yield Loss, accessed September 29, 2025, https://www.dragotec.com/blog/factors-influencing-corn-yield-loss/
Repairing what you have vs buying something else. – Red Power Magazine, accessed September 29, 2025, https://www.redpowermagazine.com/forums/topic/159324-repairing-what-you-have-vs-buying-something-else/
Soybean harvest: When the time is right | Integrated Crop Management, accessed September 29, 2025, https://crops.extension.iastate.edu/post/soybean-harvest-when-time-right
WHEN IS BUYING A NEW CORN HEAD MORE COST-EFFECTIVE THAN REPAIRING AN OLD ONE?, accessed September 29, 2025, https://www.dragotec.com/wp-content/uploads/2022/03/15298_Corn_Head_Replacement.pdf
Proper Platform Angle and Header Calibration Tips | Sloan Blog, accessed September 29, 2025, https://www.sloans.com/blog/proper-platform-angle-and-header-calibration-tips
Don’t Accept Unnecessary Loss at the Corn Head, accessed September 29, 2025, https://www.dragotec.com/blog/unnecessary-loss-at-the-corn-head/
Draper heads and a yield bump? – General Chat – Red Power Magazine Community, accessed September 29, 2025, https://www.redpowermagazine.com/forums/topic/151516-draper-heads-and-a-yield-bump/
HeadSight | Corn | Precision Planting | Upgrade Your Farm Equipment, accessed September 29, 2025, https://www.precisionplanting.com/products/headsight-corn
How to Reduce Shatter Loss at the Header in Soybeans – Calmer Corn Heads, accessed September 29, 2025, https://calmercornheads.com/troubleshoot-soybean-combine-problems/correcting-soybean-shatter-loss/
Cutting your soybean losses at harvest – Manitoba Co-operator, accessed September 29, 2025, https://www.manitobacooperator.ca/crops/cutting-your-soybean-losses-at-harvest/
A Sure Sign You’re Losing Yield: Deck Plate Wear – Drago Corn Heads, accessed September 29, 2025, https://www.dragotec.com/blog/a-sure-sign-youre-losing-yield-deck-plate-wear/
Draper Headers for Combine – Titan Machinery, accessed September 29, 2025, https://www.titanmachinery.com/docs/default-source/default-document-library/fd1—md-1005c1-2020-draper-headers-for-combine-brochure-eng-na–06-09-21.pdf?sfvrsn=b4334cb8_3
Overcoming soybean harvest challenges in 2022 – lodging and green stems, accessed September 29, 2025, https://www.canr.msu.edu/news/overcoming-soybean-harvest-challenges-shattering-green-stems-and-lodging
Combine Header Types & Must-Know Maintenance Tips – RangeLine Group Store, accessed September 29, 2025, https://www.rangelinegroup.com/blog/combine-header-types-mustknow-maintenance-tips/
What is a Flex Draper? – The Farmer’s Life, accessed September 29, 2025, https://thefarmerslife.com/flex-draper/
Top Combine and Header Tips for a Successful Soybean Harvest, accessed September 29, 2025, https://calmercornheads.com/combine-settings/tech-tips-for-bean-headers/
Are Hydraulic Deck Plates Obsolete? – AgWeb, accessed September 29, 2025, https://www.agweb.com/news/crops/crop-production/are-hydraulic-deck-plates-obsolete
Stripper-Header Revolutionized No-Till Wheat, accessed September 29, 2025, https://www.no-tillfarmer.com/articles/13274-stripper-header-revolutionized-no-till-wheat
Soybean Air Reel System: Reduce Loss & Improve ROI | The Dig – Beck’s Hybrids, accessed September 29, 2025, https://www.beckshybrids.com/resources/the-dig/soybean-air-reel-systems-reducing-loss-and-improving-roi
Reducing Soybean Harvest Losses – MSU College of Agriculture and Natural Resources – Michigan State University, accessed September 29, 2025, https://www.canr.msu.edu/resources/reducing-soybean-harvest-losses
Product History – Wallace Equipment, accessed September 29, 2025, https://www.wallaceequipment.net/wp-content/uploads/2021/04/Testimonial-Stripper-Brochure-2017.pdf
